PCB Manufacture Capability--PCB PCB制作能力 |
|
| Item 项目 | Manufacture Capability 制作能力 |
| Layers 层数 | 2-30 Layers |
| HDI | 2+N+2 |
|
Material Types 材料类型 |
FR4,Fr-5, High-Tg, Aluminum Based ,Halogen Free, |
| Isola, Taconic, Arlon, Teflon, Rogers, Copper Based | |
|
Max. Panel Dimension PCB板的最大尺寸 |
39000mil * 47000mil (1000mm * 1200mm) |
|
Outline Tolerance 外形公差 |
±4mil (±0.10mm) |
|
Board Thickness 板厚 |
8mil-236mil (0.2 - 6.0mm) |
|
Board Thickness Tolerance 板厚公差 |
±10% |
|
Dielectric Thickness 介质厚度 |
3mil-8mil ( 0.075mm-0.20mm) |
|
Min. Track Width 最小线宽 |
3mil ( 0.075mm ) |
|
Min. Track Space 最小线隙 |
3mil ( 0.075mm ) |
|
External Cu Thickness 外层铜厚 |
0.5 OZ - 10 OZ ( 17um - 350um) |
|
Internal Cu Thickness 内层铜厚 |
0.5OZ - 8OZ ( 17um - 210um) |
|
Drilling Bit Size ( CNC ) 机械钻嘴大小 |
6mil-256mil ( 0.15mm - 6.50mm) |
|
Finished Hole Size 完成孔径 |
4mil-236mil(0.1mm - 6.0mm) |
|
Hole Tolerance 孔径公差 |
±2mil (±0.05mm) |
|
Laser Drilling Hole Size 镭射钻孔尺寸 |
4mil（0.1mm） |
|
Aspect Ration 孔径纵横比 |
16:01 |
|
Solder Mask 阻焊颜色 |
Green, Blue, White, Black, Red, Yellow, Purple, etc. |
|
Min Solder mask Bridge 最小绿油桥 |
2mil(0.050mm) |
|
Plugged Hole Diameter 塞孔直径 |
8mil-20mil ( 0.20mm-0.50mm) |
|
Beveling 倒角 |
30 °- 45° |
| V-scoring | +/-0.1mm, 15° 30° 45° 60° |
|
Impedance Control 阻抗公差 |
Min.5% General ±10% |
|
Surface Finishing 表面处理 |
HASL, HASL(lead Free), Immersion Gold |
| Immersion Silver, OSP, Hard Gold ( up to 100u”) | |
|
Certificate 证书 |
UL RoHS ISO9001; ISO14000 SGS |
|
Testing 测试 |
Flying probe,E-TEST, X-RAY Inspection ,AOI |
|
Files 文件格式 |
Gerber Protel DXP Auto CAD PADS OrCAD Express PCB etc |
